NEW
BR78
Series
DC-DC Converters
1 A
Size: 0.453" x 0.354" x 0.689"
I/P : 6(8,10,13,15,20)~34 VDC
O/P:
3.3, 5, 6.5, 9, 12, 15 VDC
Operating Temp: -40~ +85°C
KEY FEATURES
| ◆ | Wide Input Voltage Range, Non-Isolated & Regulated Single Output | |||
| ◆ | High Efficiency up to 96% | |||
| ◆ | No Load Input Current as Low as 0.2mA | |||
| ◆ | Short Circuit Protection | |||
| ◆ | Plastic Case, Meet UL94 V-0 Standard | |||
| ◆ | Wide Operating Temperature: -40°C~+85°C with derating | |||
| ◆ | 3-Year Product Warranty | |||
MECHANICAL DIMENSIONS
| Package | SIP |
| Dimensions | 11.5 x 9.0 x 17.5 mm 0.453 x 0.354 x 0.689 inches |
| ■ | Please refer to the PDF file published on the web site as the final version. | |||
| ■ | We reserve the right to make alterations in the product materials and specifications without prior notification and consent to improve reliability, function or design or otherwise. | |||
