AVC
Series
AC-DC ITE Power Module
15 Watt
Size: 1.62" x 1.07" x 0.75"
I/P: 90~264VAC
O/P: 5, 12, 15, 24 VDC
I/O Isolation: 4000VAC
Operating Temp: -40~ +70°C
KEY FEATURES
| ◆ | Ultra Compact Power Module for PCB Mountable | |||
| ◆ | Universal Input Range 90-264VAC | |||
| ◆ | Low No-Load Power Consumption < 0.1W | |||
| ◆ | Cooling by free air convection | |||
| ◆ | Wide Operating Temperature: -40°C~+70°C with derating | |||
| ◆ | Low Ripple and Noise | |||
| ◆ | Isolation Class II | |||
| ◆ | I/O Isolation: 4000VAC | |||
| ◆ | Safety Approval to IEC / EN 60950, UL / IEC / EN 62368-1 | |||
| ◆ | 3-Year Product Warranty | |||
ELECTRICAL CHARACTERISTICS
| Package | Module |
| Dimensions | 41.2 x 27.2 x 19.1 mm 1.62 x 1.07 x 0.75 inches |
| No Load Power | <0.1W |
| Line Regulation | ±0.5% |
| Load Regulation | ±1% |
| Ripple and Noise | 5S:100mV 12S:120mV 15S:150mV 24S:240mV |
| Agency Approvals | |
| IEC / EN 60950, UL / IEC / EN 62368-1 | |
| EMI | EN 55032 Class B |
| EMS | EN 55024 |
| ■ | Please refer to the PDF file published on the web site as the final version. | |||
| ■ | We reserve the right to make alterations in the product materials and specifications without prior notification and consent to improve reliability, function or design or otherwise. | |||
