MQC100

Series

AC-DC ITE Power Module
AC-DC Medical Power Module

100 Watt

Size: 4.3" x 2.3" x 1.38"
I/P: 90~264VAC
O/P: 12, 24, 48 VDC
I/O Isolation: 4000VAC
Operating Temp: -30~ +70°C






KEY FEATURES
◆  Ultra Compact Power Module for PCB Mountable
◆  Universal Input Range 90-264VAC
◆  Low No-Load Power Consumption < 0.5W
◆  Cooling by free air convection
◆  Low Leakage Current < 0.1mA / 264 VAC (Touch Current)
◆  Wide Operating Temperature: -30°C~+70°C with derating
◆  High Efficiency up to 93.5%
◆  I/O Isolation: 4000VAC
◆  EMI for Both Class I (with PE) and Class II (without PE) Configuration
◆  Suitable for BF Application with Appropriate System Consideration
◆  Safety Approval to UL / IEC / EN 60601 3.1rd Edition (2 x MOPP), UL / IEC / EN 60950 AM2, UL / IEC / EN 62368
◆  Medical safety approved, 2xMOPP
◆  3-Year Product Warranty


ELECTRICAL CHARACTERISTICS
PackageModule
Dimensions109.0 x 58.5 x 35.0 mm
4.3 x 2.3 x 1.38 inches

No Load Power<0.5W
Line Regulation±%
Load Regulation±1%
Ripple and Noise1% Vout
Agency Approvals
 UL / IEC / EN 60601 3.1rd Edition (2 x MOPP),
UL / IEC / EN 60950 AM2,
UL / IEC / EN 62368

EMI
ConductedEN 55011 Class B
RadiatedEN 55011 Class I class B / Class II class A
EMSEN 60601-1-2 4th Edition



Please refer to the PDF file published on the web site as the final version.
We reserve the right to make alterations in the product materials and specifications without prior notification and consent to improve reliability, function or design or otherwise.
